Sanyo NCR18650GA 3.6V 3500mAh 10A High Power Cell
Sanyo NCR18650GA 3.6V 3500mAh 10A High Power Unprotected Cell
***Batteries purchased without any equipment they can operate must be shipped with ground shipping. If you purchase only batteries and no flashlights/headlamps you must select UPS Ground even if other options are available unless your order meets the free shipping threshold.***
If out of stock please consider the Molicel M35A for similar performance.
Max. continuous discharge: 10A
Nominal capacity: 3500mAh
Nominal Voltage 3.6V
Standard charge: Constant Current: 1475mA
Charging Time Std. 270 min.
Max. Charge Voltage 4.20 ± 0.05 V
Max. continuous discharge
10A
Discharge cut-off voltage
End of discharge 2.5V
( 2.5V discharge cut-off is better in cycle life )
Cell weight :48.0g max.
Cell dimension:
Height : 65.3mm max.
Diameter : 18.5 mm max.
Operating temperature (surface temperature)
Charge : 10 to 45 (recommended recharge release < 45°C)
Discharge: -20 to 60 (recommended re-discharge release < 60°C)
Applications: Suitable for most electronic devices, especially power tools such as e-bike and drills, e-cigarettes, and power tools.
